A reratctable plunger with a non-locking nose and a nylon patch by Delrin

Delrin® – Non Locking Nose With Nylon Patch

Product Description

Non Locking Delrin® Knob Plungers, With Nylon Patch.  Made from your choice of zinc plated 12L15 steel and 303 Stainless Steel.  Radiused nose for smooth mating hole engagement.  Withstands side loading.  With thread locking element.

Steel P/N Stainless P/N Thread (A) Thread Length (C) Body Length (B) Nose Length (D) Nose Dia (E) Start End Force (lbs) Final End Force (lbs)
DKNW25 SDKNW25 1/4-20 0.63 0.97 0.13 0.16 0.12 0.36
DKNW38 SDKNW38 3/8-16 0.75 1.40 0.18 0.25 0.25 2.00
DKNW50 SDKNW50 1/2-13 1.00 1.90 0.25 0.31 0.50 1.75
